Produktinformationen "D&R Airence USB Main Unit"
INTRODUCTION
With the AIRENCE-USB ON-AIR mixer you can own a modern, split version type of radio production mixer. A smart mixer with an integrated USB based control section. Built with well proven low noise circuitry, this console is the reliable workhorse for the self-op production D.J. Built in Telephone Hybrids (2x), 4 channels USB and 4 Mic inputs. Ideal for streaming to the web and sending and accepting 4 stereo channels from your Play-out software.
A heavy duty (19" rack) RF shielded chassis, that can be used as a drop through in your furniture, houses all the vertically mounted input modules. Extension units with six triple input channels with high end quality Mic inputs on XLR and two stereo line level inputs on Cinch (RCA) connectors can be connected to the main unit. The result is a modern split drop through 12 (or 18/24) fader radio console.
MIC, LINE, USB AND TELEPHONE IN-OUTPUTS
This brand new AIRENCE-USB model has 4 balanced mic inputs (+48 phantom is standard) with inserts for signal processors, 6 stereo line inputs, 4x USB channels and 2x Telephone Hybrids. If you would like to call with VOIP we would advice to use the CISCO SPA112 as an interface between our 2 Telephone modules and the Internet.
One physical USB connection interfaces 4 stereo audio channels from and to your PC plus all (programmable) remote controls on the right hand section of the mixer. Channel 5 and 6 have, apart from the stereo line input, also RJ-11 connectors to interface with an analogue telephone line and a common dial unit.
High quality built in Hybrids with R and C balance and direct Talk back to the Hybrid channels makes conversation with callers very easy. Also by simply pushing the Cue button, conversation between DJ and caller outside the broadcast is of course possible.
The illuminated front panel ON switch is electronically attached to the built in mechanical fader start enabling selection of a play-out start either by fader or via the ON switch. Fader start generates in the Mic mode a Mic-on signaling to switch ON-Air lights. There is a 3 band Equalizer on channel 1-4 and on all 6 Triple input channels of the Extender Unit. The stereo Aux send can be set pre or post fader. All high quality low noise mic inputs have low cut jumpers.
EXTENSIVE MASTER SECTION DESIGNED WITH RADIO IN MIND
The AIRENCE-USB has all the master controls such as 100 mm stereo master faders, stereo Aux send and return, monitor master with "follow phones" and a phones output with a split listen function.
INPUTS
Mic inputs:
bal, 2 kOhm, XLR. ,48 volt Phantom.
Noise: - 128 dBr (A-weighted). (That 1501)Sensitivity: - 70dB min, OdB Max.
Insert: Jack unbalanced send 600 Ohm -10dBV.
Aux Return unbalanced 10kOhm -10dBv.
Line inputs: unbal.., 10kOhm, Cinch.
Gain: range of 40dB.
Phono inputs: unbal. 47kOhm, 5 mV. (optional)
USB: 4x Stereo in and 4x stereo out.
Extern in: - 10 dBV at 10kOhm.
Aux returns: - 10 dBv at 10kOhm stereo
USB
Fully compliant with USB 2.0 playback and record mode. 4x Stereo in and Main stereo or SUB signals out.
HID Functions: Volume|Mute|Control
USB CONTROL SECTION
24 free assignable illuminated switches plus encoder based on the HID protocol.
TELEPHONE HYBRIDS
RJ-11 connectors for phone line/dialler
Mix Minus rejection @1kHz -40dB.
OUTPUTS
Left/Right: + 6dBu bal. XLR.
Monitor/Aux : + 6dBu unbal. on Cinch.
Studio: + 6dBu, Jacks. Tape outp: -10dBv.
Headphone: 32-600 Ohm, Jack.
Announcer: 32-600 Ohm, Jack.
USB out: Main program stereo signal or SUB
EQUALIZER
High: + / -12 dB at 12kHz shelving.
Mid: + / -12dB at 1 kHz bell curve.
Low: + / -12dB at 60 Hz shelving.
POWER
A High efficient (level 5) switched digital power supply will be supplied with every individual unit.
Input range is 100-240volt|47-63Hz
Power consumption is 60 watt.
Also an extra redundancy back supply can be connected to the main unit.
OVERALL
Frequency response: 10 - 60.000Hz.
Distortion: < 0.01% max at 1 kHz.
Start switch: isolated reed relay. (24volt/50mA)
Ledbars: 11 segment and on high res on screen
SOFTWARE
A software protocol is available for programming of the USB HID protocol to match your software.
DIMENSIONS
Main unit
Width: 482mm, Front Panel Thickness: 2mm
Corner Radius: 20 mm
Height: 355mm
Depth: 101.50mm.
Weight: 9kg.
Drop through hole: 450mm x 344mm
Extension unit
Width: 302mm, Front Panel Thickness: 2mm
Corner Radius: 20 mm
Height: 355mm
Depth: 101.50mm.
Weight: 7kg.
Drop through hole: 270mm x 344mm
