AX32 is your audio routing centerpiece, digital format converter, world-class AD/DA converter and monitor controller. Quite simply, AX32 changes seamlessly between workflows in seconds, optimizing your production time and efficiency.
With the AX32you get pristine AD and DA conversion with superb sonic quality, versatile I/O structure and IP Audio via Layer 3 Ethernet (Dante) that follows the track of the AX24 with an enhanced performance in terms the sonic quality of the AD andDA conversion, up-to 48 analogue audio channels and a flexible digital signalinterface, routing and distribution structure.
With all I/O card and options installed, you can control a 1,500 x 1,500 matrix of audiochannels. 8 I/O cards and 2 I/O modules can be installed. Just imagine the flexibility and swift change between workflows you would have right at yourfingertips.
All operation and functional control is managed via the DADman control software.
FLEXIBLE AD/DA INTERFACE CONFIGURATION W/ MIC-PRE OPTION
Versatile digital interface structure
Easy control of converter parameters
8 to 48 analogue channels
8 channels on a card. Up-to 6 analogue card can be installed
8 ch. Line in AD card and 8 ch. Line/Mic pre in AD card
8 ch. Line out DA card with output level control
Sample rates 44.1 kHz up-to 384 kHz/DSD
High precision internal clock and PLL
VERSATILE DIGITAL INTERFACE STRUCTURE
8 AES3 I/O interfaces
MADI coax and optical I/O
3G SDI embedded audio I/O
Ethernet IP audio interface for 64 I/O channels using Dante(TM)
Synch via word clock, AES11, Video, and all digital I/O
Adapt to incoming sample rate
EASY CONTROL OF CONVERTER PARAMETERS
Settings control via front panel knobs and large LCD display
Operation via DADman control software for Windows and OSX
Ethernet control interface
Compliant with the Dante Ethernet controller
Features
Thunderbolt 3 interface, with 256 Bidirectional Channels at 48 & 96 kHz, 128 channels at 192 kHz and 64 channels at 384 kHz.
Main and expansion Thunderbolt 3 Port w. 15W Power Source Each. Both of the two Thunderbolt 3 ports can function as main and expansion port.
Audio Drivers for macOS and Windows.
MADI interface on BNC connectors with 64 Bidirectional Channels at 48kHz, 32 channels at 96kHz, 16 channels at 192 kHz and 8 channels at 384 kHz.
Dual ADAT interface on TosLink Light pipes with 16 Bidirectional Channels at 48kHz, 8 channels at 96kHz, and 4 channels at 192 kHz. Configurable also as 2 Ch. S/PDIF input.
DANTE AoIP interface via Ethernet with 256 Bidirectional Channels at 48 and 96kHz, 128 channels at 192 kHz.
Module Slot for optional dual Madi module via 2 x SFP (LC Fiber or HD/BNC Coax) connectors with 128 Bidirectional Channels at 48kHz, 64 channels at 96kHz, 32 channels at 192 kHz and 16 channels at 384 kHz.
wo card slots available for DAD I/O Expansion Cards.
Word Clock I/O, and Video Black and Burst input on BNC connectors.
128 channels speaker processing with a total of 1024 filters and delay.
Summing Processor 64 Output / 512 Input Busses.
Internal Router: 4096 x 4096.
32bit Floating Point Processing.
DADman control software for macOS and Windows connecting via Ethernet or Thunderbolt.
Pro|Mon monitor control functionality and integration for Avid Eucon Enabled Devices via DADman.
19” Rack Unit 1U Height.
Technical Overview
2 Ch. microphone or instrument input
Dual stereo headphone output
Dual stereo monitor output
A/D, D/A and D/D Converter with sample rates from 44,1 to 384 kHz and DSD
Up to 984 Input and Output Channels
Router and Monitoring Interface
Thunderbolt 3 I/O (256 Ch.)
Dante AoIP I/O (256 Ch.)
MADI I/O (64 ch.)
ADAT I/O (16 Ch.) / SPDIF (2 ch.)
2 Slots for Optional Multi-Format DAD I/O Cards
512x64 Ch. Pro|Mon Summing and Speaker 1024 ch. EQ Processing
AX32-CARD-M8
Flexible AD/DA interface configuration, with mic-pre option.AX32 allows you to configure the number of AD Line and Mic channels and DA channels that you need. Analogue input and output channels can be configured in groups of eight for a total of 32 combined input and output channels. All input channels can be installed with mic-pres in pairs of two. The AX32 can be configured as only DA or AD or a combination here of.The AX32 mic-pres has an outstanding performance with an equivalent input noise below -133 dB, and gain steps circuitry with relays ensuring that no un-linearly distortion is added to the sensitive microphone signal when amplified.The AX32 DA converter provides high-performance output level and gain control. With a level stepscircuitry using relays the outputs can directly drive a monitoring system, ensuring high dynamic range and no disturbing clicks when changing formats or powering down.Versatile digital interface structure.AX32 has a fixed configuration of digital interfaces for connecting via AES/EBU, S/PDIF, MADI, Pro Tools® and IP Ethernet audio compliant to Dante. One additional card slot is available for other interfaces which can be optionally installed. Currently this slot can hold an optical MADI or S/PDIF TosLink interface .Sync interfaces via word clock, AES11, Video, and all digital signal inputs. Sample rate can be set to internal or external, The sample rate can be set via all external devices.Rear panel layoutA total of 8 card slots are available in the chassis frame. 4 slots can be used for analogue cards each with 8 channels giving a total of 32 AD/DA input and outputs.The standard interface has the following capability:
8 AES3 I/O on two D25 connectors with 16 mono channels
MADI I/O on BNC connectors with 64 mono channels
Interface for Protools on SDR (min) connectors with 16 or 32 mono I/O channels
Interface for IP Ethernet audio on two redundant RJ45
connectors with 64 mono I/O channels powered by Dante
Flexible AD/DA interface configuration, with mic-pre option
8 to 32 channel AD/DA
8 channels on a card
AD Mic-pre option
DA gain control
Sample rates 44,1 kHz up-to 384 kHz/DSD
High precision internal clock and PLL
Versatile digital interface structure
8 AES3 I/O interfaces
MADI coax and optical I/O
Interface for Pro Tools (TM)
Ethernet IP audio interface for 64 I/O channels using Dante(TM)
Synch via word clock, AES11, Video, and all digital I/O
Adapt to incoming sample rate
Optional channel patching and multiplexer engine
Easy control of converter parameters
Settings control via front panel knobs and large LCD display
Operation via DADman control software for Windows and OSX
Ethernet control interface
Compliant with the Dante Ethernet controlle
AX32-CARD-M8
Flexible AD/DA interface configuration, with mic-pre option.AX32 allows you to configure the number of AD Line and Mic channels and DA channels that you need. Analogue input and output channels can be configured in groups of eight for a total of 32 combined input and output channels. All input channels can be installed with mic-pres in pairs of two. The AX32 can be configured as only DA or AD or a combination here of.The AX32 mic-pres has an outstanding performance with an equivalent input noise below -133 dB, and gain steps circuitry with relays ensuring that no un-linearly distortion is added to the sensitive microphone signal when amplified.The AX32 DA converter provides high-performance output level and gain control. With a level stepscircuitry using relays the outputs can directly drive a monitoring system, ensuring high dynamic range and no disturbing clicks when changing formats or powering down.Versatile digital interface structure.AX32 has a fixed configuration of digital interfaces for connecting via AES/EBU, S/PDIF, MADI, Pro Tools® and IP Ethernet audio compliant to Dante. One additional card slot is available for other interfaces which can be optionally installed. Currently this slot can hold an optical MADI or S/PDIF TosLink interface .Sync interfaces via word clock, AES11, Video, and all digital signal inputs. Sample rate can be set to internal or external, The sample rate can be set via all external devices.Rear panel layoutA total of 8 card slots are available in the chassis frame. 4 slots can be used for analogue cards each with 8 channels giving a total of 32 AD/DA input and outputs.The standard interface has the following capability:
8 AES3 I/O on two D25 connectors with 16 mono channels
MADI I/O on BNC connectors with 64 mono channels
Interface for Protools on SDR (min) connectors with 16 or 32 mono I/O channels
Interface for IP Ethernet audio on two redundant RJ45
connectors with 64 mono I/O channels powered by Dante
Flexible AD/DA interface configuration, with mic-pre option
8 to 32 channel AD/DA
8 channels on a card
AD Mic-pre option
DA gain control
Sample rates 44,1 kHz up-to 384 kHz/DSD
High precision internal clock and PLL
Versatile digital interface structure
8 AES3 I/O interfaces
MADI coax and optical I/O
Interface for Pro Tools (TM)
Ethernet IP audio interface for 64 I/O channels using Dante(TM)
Synch via word clock, AES11, Video, and all digital I/O
Adapt to incoming sample rate
Optional channel patching and multiplexer engine
Easy control of converter parameters
Settings control via front panel knobs and large LCD display
Operation via DADman control software for Windows and OSX
Ethernet control interface
Compliant with the Dante Ethernet controlle
AX32-CARD-M8
Flexible AD/DA interface configuration, with mic-pre option.AX32 allows you to configure the number of AD Line and Mic channels and DA channels that you need. Analogue input and output channels can be configured in groups of eight for a total of 32 combined input and output channels. All input channels can be installed with mic-pres in pairs of two. The AX32 can be configured as only DA or AD or a combination here of.The AX32 mic-pres has an outstanding performance with an equivalent input noise below -133 dB, and gain steps circuitry with relays ensuring that no un-linearly distortion is added to the sensitive microphone signal when amplified.The AX32 DA converter provides high-performance output level and gain control. With a level stepscircuitry using relays the outputs can directly drive a monitoring system, ensuring high dynamic range and no disturbing clicks when changing formats or powering down.Versatile digital interface structure.AX32 has a fixed configuration of digital interfaces for connecting via AES/EBU, S/PDIF, MADI, Pro Tools® and IP Ethernet audio compliant to Dante. One additional card slot is available for other interfaces which can be optionally installed. Currently this slot can hold an optical MADI or S/PDIF TosLink interface .Sync interfaces via word clock, AES11, Video, and all digital signal inputs. Sample rate can be set to internal or external, The sample rate can be set via all external devices.Rear panel layoutA total of 8 card slots are available in the chassis frame. 4 slots can be used for analogue cards each with 8 channels giving a total of 32 AD/DA input and outputs.The standard interface has the following capability:
8 AES3 I/O on two D25 connectors with 16 mono channels
MADI I/O on BNC connectors with 64 mono channels
Interface for Protools on SDR (min) connectors with 16 or 32 mono I/O channels
Interface for IP Ethernet audio on two redundant RJ45
connectors with 64 mono I/O channels powered by Dante
Flexible AD/DA interface configuration, with mic-pre option
8 to 32 channel AD/DA
8 channels on a card
AD Mic-pre option
DA gain control
Sample rates 44,1 kHz up-to 384 kHz/DSD
High precision internal clock and PLL
Versatile digital interface structure
8 AES3 I/O interfaces
MADI coax and optical I/O
Interface for Pro Tools (TM)
Ethernet IP audio interface for 64 I/O channels using Dante(TM)
Synch via word clock, AES11, Video, and all digital I/O
Adapt to incoming sample rate
Optional channel patching and multiplexer engine
Easy control of converter parameters
Settings control via front panel knobs and large LCD display
Operation via DADman control software for Windows and OSX
Ethernet control interface
Compliant with the Dante Ethernet controlle
AX32-MADI-OPT
Flexible AD/DA interface configuration, with mic-pre option.AX32 allows you to configure the number of AD Line and Mic channels and DA channels that you need. Analogue input and output channels can be configured in groups of eight for a total of 32 combined input and output channels. All input channels can be installed with mic-pres in pairs of two. The AX32 can be configured as only DA or AD or a combination here of.The AX32 mic-pres has an outstanding performance with an equivalent input noise below -133 dB, and gain steps circuitry with relays ensuring that no un-linearly distortion is added to the sensitive microphone signal when amplified.The AX32 DA converter provides high-performance output level and gain control. With a level stepscircuitry using relays the outputs can directly drive a monitoring system, ensuring high dynamic range and no disturbing clicks when changing formats or powering down.Versatile digital interface structure.AX32 has a fixed configuration of digital interfaces for connecting via AES/EBU, S/PDIF, MADI, Pro Tools® and IP Ethernet audio compliant to Dante. One additional card slot is available for other interfaces which can be optionally installed. Currently this slot can hold an optical MADI or S/PDIF TosLink interface .Sync interfaces via word clock, AES11, Video, and all digital signal inputs. Sample rate can be set to internal or external, The sample rate can be set via all external devices.Rear panel layoutA total of 8 card slots are available in the chassis frame. 4 slots can be used for analogue cards each with 8 channels giving a total of 32 AD/DA input and outputs.The standard interface has the following capability:
8 AES3 I/O on two D25 connectors with 16 mono channels
MADI I/O on BNC connectors with 64 mono channels
Interface for Protools on SDR (min) connectors with 16 or 32 mono I/O channels
Interface for IP Ethernet audio on two redundant RJ45
connectors with 64 mono I/O channels powered by Dante
Flexible AD/DA interface configuration, with mic-pre option
8 to 32 channel AD/DA
8 channels on a card
AD Mic-pre option
DA gain control
Sample rates 44,1 kHz up-to 384 kHz/DSD
High precision internal clock and PLL
Versatile digital interface structure
8 AES3 I/O interfaces
MADI coax and optical I/O
Interface for Pro Tools (TM)
Ethernet IP audio interface for 64 I/O channels using Dante(TM)
Synch via word clock, AES11, Video, and all digital I/O
Adapt to incoming sample rate
Optional channel patching and multiplexer engine
Easy control of converter parameters
Settings control via front panel knobs and large LCD display
Operation via DADman control software for Windows and OSX
Ethernet control interface
Compliant with the Dante Ethernet controlle
AX32-CARD-M8
Flexible AD/DA interface configuration, with mic-pre option.AX32 allows you to configure the number of AD Line and Mic channels and DA channels that you need. Analogue input and output channels can be configured in groups of eight for a total of 32 combined input and output channels. All input channels can be installed with mic-pres in pairs of two. The AX32 can be configured as only DA or AD or a combination here of.The AX32 mic-pres has an outstanding performance with an equivalent input noise below -133 dB, and gain steps circuitry with relays ensuring that no un-linearly distortion is added to the sensitive microphone signal when amplified.The AX32 DA converter provides high-performance output level and gain control. With a level stepscircuitry using relays the outputs can directly drive a monitoring system, ensuring high dynamic range and no disturbing clicks when changing formats or powering down.Versatile digital interface structure.AX32 has a fixed configuration of digital interfaces for connecting via AES/EBU, S/PDIF, MADI, Pro Tools® and IP Ethernet audio compliant to Dante. One additional card slot is available for other interfaces which can be optionally installed. Currently this slot can hold an optical MADI or S/PDIF TosLink interface .Sync interfaces via word clock, AES11, Video, and all digital signal inputs. Sample rate can be set to internal or external, The sample rate can be set via all external devices.Rear panel layoutA total of 8 card slots are available in the chassis frame. 4 slots can be used for analogue cards each with 8 channels giving a total of 32 AD/DA input and outputs.The standard interface has the following capability:
8 AES3 I/O on two D25 connectors with 16 mono channels
MADI I/O on BNC connectors with 64 mono channels
Interface for Protools on SDR (min) connectors with 16 or 32 mono I/O channels
Interface for IP Ethernet audio on two redundant RJ45
connectors with 64 mono I/O channels powered by Dante
Flexible AD/DA interface configuration, with mic-pre option
8 to 32 channel AD/DA
8 channels on a card
AD Mic-pre option
DA gain control
Sample rates 44,1 kHz up-to 384 kHz/DSD
High precision internal clock and PLL
Versatile digital interface structure
8 AES3 I/O interfaces
MADI coax and optical I/O
Interface for Pro Tools (TM)
Ethernet IP audio interface for 64 I/O channels using Dante(TM)
Synch via word clock, AES11, Video, and all digital I/O
Adapt to incoming sample rate
Optional channel patching and multiplexer engine
Easy control of converter parameters
Settings control via front panel knobs and large LCD display
Operation via DADman control software for Windows and OSX
Ethernet control interface
Compliant with the Dante Ethernet controlle
CARD-DA8
Flexible AD/DA interface configuration, with mic-pre option.AX32 allows you to configure the number of AD Line and Mic channels and DA channels that you need. Analogue input and output channels can be configured in groups of eight for a total of 32 combined input and output channels. All input channels can be installed with mic-pres in pairs of two. The AX32 can be configured as only DA or AD or a combination here of.The AX32 mic-pres has an outstanding performance with an equivalent input noise below -133 dB, and gain steps circuitry with relays ensuring that no un-linearly distortion is added to the sensitive microphone signal when amplified.The AX32 DA converter provides high-performance output level and gain control. With a level stepscircuitry using relays the outputs can directly drive a monitoring system, ensuring high dynamic range and no disturbing clicks when changing formats or powering down.Versatile digital interface structure.AX32 has a fixed configuration of digital interfaces for connecting via AES/EBU, S/PDIF, MADI, Pro Tools® and IP Ethernet audio compliant to Dante. One additional card slot is available for other interfaces which can be optionally installed. Currently this slot can hold an optical MADI or S/PDIF TosLink interface .Sync interfaces via word clock, AES11, Video, and all digital signal inputs. Sample rate can be set to internal or external, The sample rate can be set via all external devices.Rear panel layoutA total of 8 card slots are available in the chassis frame. 4 slots can be used for analogue cards each with 8 channels giving a total of 32 AD/DA input and outputs.The standard interface has the following capability:
8 AES3 I/O on two D25 connectors with 16 mono channels
MADI I/O on BNC connectors with 64 mono channels
Interface for Protools on SDR (min) connectors with 16 or 32 mono I/O channels
Interface for IP Ethernet audio on two redundant RJ45
connectors with 64 mono I/O channels powered by Dante
Flexible AD/DA interface configuration, with mic-pre option
8 to 32 channel AD/DA
8 channels on a card
AD Mic-pre option
DA gain control
Sample rates 44,1 kHz up-to 384 kHz/DSD
High precision internal clock and PLL
Versatile digital interface structure
8 AES3 I/O interfaces
MADI coax and optical I/O
Interface for Pro Tools (TM)
Ethernet IP audio interface for 64 I/O channels using Dante(TM)
Synch via word clock, AES11, Video, and all digital I/O
Adapt to incoming sample rate
Optional channel patching and multiplexer engine
Easy control of converter parameters
Settings control via front panel knobs and large LCD display
Operation via DADman control software for Windows and OSX
Ethernet control interface
Compliant with the Dante Ethernet controlle
AX32-CARD-L8Flexible AD/DA interface configuration, with mic-pre option.AX32 allows you to configure the number of AD Line and Mic channels and DA channels that you need. Analogue input and output channels can be configured in groups of eight for a total of 32 combined input and output channels. All input channels can be installed with mic-pres in pairs of two. The AX32 can be configured as only DA or AD or a combination here of.The AX32 mic-pres has an outstanding performance with an equivalent input noise below -133 dB, and gain steps circuitry with relays ensuring that no un-linearly distortion is added to the sensitive microphone signal when amplified.The AX32 DA converter provides high-performance output level and gain control. With a level stepscircuitry using relays the outputs can directly drive a monitoring system, ensuring high dynamic range and no disturbing clicks when changing formats or powering down.Versatile digital interface structure.AX32 has a fixed configuration of digital interfaces for connecting via AES/EBU, S/PDIF, MADI, Pro Tools® and IP Ethernet audio compliant to Dante. One additional card slot is available for other interfaces which can be optionally installed. Currently this slot can hold an optical MADI or S/PDIF TosLink interface .Sync interfaces via word clock, AES11, Video, and all digital signal inputs. Sample rate can be set to internal or external, The sample rate can be set via all external devices.Rear panel layoutA total of 8 card slots are available in the chassis frame. 4 slots can be used for analogue cards each with 8 channels giving a total of 32 AD/DA input and outputs.The standard interface has the following capability:
8 AES3 I/O on two D25 connectors with 16 mono channels
MADI I/O on BNC connectors with 64 mono channels
Interface for Protools on SDR (min) connectors with 16 or 32 mono I/O channels
Interface for IP Ethernet audio on two redundant RJ45
connectors with 64 mono I/O channels powered by Dante
Flexible AD/DA interface configuration, with mic-pre option
8 to 32 channel AD/DA
8 channels on a card
AD Mic-pre option
DA gain control
Sample rates 44,1 kHz up-to 384 kHz/DSD
High precision internal clock and PLL
Versatile digital interface structure
8 AES3 I/O interfaces
MADI coax and optical I/O
Interface for Pro Tools (TM)
Ethernet IP audio interface for 64 I/O channels using Dante(TM)
Synch via word clock, AES11, Video, and all digital I/O
Adapt to incoming sample rate
Optional channel patching and multiplexer engine
Easy control of converter parameters
Settings control via front panel knobs and large LCD display
Operation via DADman control software for Windows and OSX
Ethernet control interface
Compliant with the Dante Ethernet controlle
Das AX32 verfügt über 8 AES3-Eingänge und -Ausgänge auf zwei D25-Anschlüssen
mit insgesamt 16 Monokanälen sowie MADI-Ein- und -Ausgänge auf BNC-Anschlüssen mit insgesamt 64 Monokanälen.Es bietet auch eine Schnittstelle für die IP-Ethernet-Steuerung. Wenn Sie das AX32 als 64-Kanal-Interface für Pro Tools (TM) verwenden möchten, können Sie das MTRX von Avid einsetzen, das im Wesentlichen ein AX32 mit zusätzlicher DigiLink-Konnektivität ist. OPTIONALE E/A-SCHNITTSTELLENIm Chassisrahmen stehen
insgesamt 8 Kartensteckplätze zur Verfügung. Davon können Sie 6 Steckplätze für analoge Karten mit jeweils 8 Kanälen nutzen, was insgesamt bis zu 48 AD/DA Ein- und Ausgänge ermöglicht.Folgende Karten
stehen zur Verfügung: - 8-Kanal
Line Pristine
A/D-Karte - 8-Kanal Mic/Line Pristine
A/D-Karte - 8-Kanal Pristine-D/A-Karte - Dante 128-Kanal-E/A-Karte mit SRC - Dual SDI/HD/3G 2x16 kanalige Emb/Deembed-Karte mit SRC - Du erhältst eine 8-Kanal AES3-E/A-Karte mit
SRC und eine doppelte MADI-128-Kanal-I/O-Karte.Das Mainframe-Gehäuse kann um weitere Komponenten erweitert werden, wie zum Beispiel
Dante IP-Audio auf zwei redundanten RJ45-Anschlüssen mit 64 Mono-E/A-Kanälen
und 2 x 64 MADI-Kanälen auf optischen oder koaxialen Anschlüssen.Schließlich können Sie einen oder mehrere Erweiterungssteckplätze für die SPQ Speaker Processing DSP-Karte zuweisen. Diese Karte bietet keine zusätzlichen Ein- oder Ausgänge, sondern ermöglicht die Anwendung von 1.024 individuellen EQ-Filtern zur Raumkorrektur der Lautsprecher auf bis zu 128 Kanälen.
Up to 8 analogue cards can be installed, providing 64 analogue input or output audio channels with the renowned DAD high-end sonic quality.
With tons of channels, a wide palette of digital connectivity, built-in SPQ processing, Eucon control compatibility, internal summing engine and drivers for macOS and Windows 10, it is a pristine digital audio interface by any measure and is suited for just about any application.
In short, AX64 is the ultimate modular multi-format interface, which is ready to take on a wealth of tasks in the Post Production, Studio, Live Music and Installed Audio spheres.
Overview
• 1,744 Input and Output Channels• Multi-Format Audio A/D, D/A and D/D Converter• Digital Router and Monitoring Interface (Analog expansion available, but not included)• Thunderbolt 3 I/O (256 Ch.)• Dante AoIP I/O (256 Ch.)• MADI I/O (64 Ch.)• MADI SFP I/O Module Option Available (128 Ch. – SFP not included)• ADAT I/O (16 Ch.)• 8 Slots for Optional Multi-Format DAD I/O Cards• 512x64 Ch. Pro|Mon Summing and Speaker EQ Processing
Features
The basic I/O configuration for the AX64 multi-format interface is:
• 2 Thunderbolt 3 Ports (each w. 15W power)• 256 Bidirectional Channels at 48 & 96 kHz• ASIO / Core Audio Thunderbolt PCIe Drivers• MADI/BNC-Optional 2 x SFP (LC fiber or HD/BNC coax)• ADAT /Lightpipe (16 Ch.)• DANTE: 256 Ch. at 48 kHz, 128 Ch. at 96kHz, 64 Ch. at 192 kHz (IP Core)• WC I/O • SPQ: 64 Ch. with 16 Filters• Pro|Mon Support• Summing Processor 64 Output / 512 Input Busses• Internal Router: 4096 x 4096• 32bit Floating Point Processing• 8 Slots for Any Available Expansion Cards• Avid Eucon Enabled Devices via DADman• Apple Silicon M1 and Intel Compatible Software• Control via Ethernet or Thunderbolt Connection• Dual 110/240V AC Power Connection as Option
Currently Available Expansion Cards:
• 8 Analogue Inputs (Line Signal)• 8 Analogue Inputs (Mic Preamps)• 8 Analogue Outputs (Line Signal)• Dante Card (128 Ch.)• Dual MADI Card (2 x 64 Ch.)• AES Card (16 Ch.)• Dual MADI Module (2 x 64 Ch.)
Core 256 may not take up much space, but the power you can squeeze out of this little box might just make your jaw drop to the floor. With tons of channels, a wide palette of digital connectivity, built-in SPQ processing, Eucon control compatibility, internal summing engine and drivers for macOS and Windows 10, it is a pristine digital audio interface by any measure and for just about any application.
However, there is one application that should be emphasized in particular: Core 256 is simply the perfect Dante and MADI interface for Dolby Atmos® RMU.
The size and shape of Core 256 fits nicely for sharing a 1U rack shelf with a Mac Mini running Dolby Atmos® Renderer, Dolby Atmos® Production Suite or Dolby Atmos® Mastering Suite. For immersive audio post production facilities, this solution will represent the missing link that streamlines and optimizes the multichannel workflows seamlessly.
Features
The basic I/O configuration for the Core 256 interface is:
• 2 Thunderbolt 3 Ports (each w. 15W power)• 256 Bidirectional Channels at 48 & 96 kHz• ASIO / Core Audio Thunderbolt PCIe drivers• MADI/BNC-Optional 2 x SFP (LC fiber or HD/BNC coax)• ADAT /Lightpipe (16 Ch.)• DANTE: 256 Ch. at 48 kHz, 128 Ch. at 96 kHz, 64 Ch. at 192 kHz (IP Core)• WC I/O• SPQ: 64 Ch. with 16 Filters• Pro|Mon Support• Summing Processor 64 Output / 512 Input Busses• Internal Router: 1500 x 1500• 32bit Floating Point Processing• Avid Eucon Enabled Devices via DADman• APPLE Silicon M1 and Intel Compatible Software• Control via Ethernet or Thunderbolt Connection• 12V DC External Power (Max 60W)• ½ Rack Unit 1U Height
Further, the mini module slot can be mounted with an optional dual bidirectional MADI module with optical SFP or mini coax connectors.
AX32-MADI-OPT
Flexible AD/DA interface configuration, with mic-pre option.AX32 allows you to configure the number of AD Line and Mic channels and DA channels that you need. Analogue input and output channels can be configured in groups of eight for a total of 32 combined input and output channels. All input channels can be installed with mic-pres in pairs of two. The AX32 can be configured as only DA or AD or a combination here of.The AX32 mic-pres has an outstanding performance with an equivalent input noise below -133 dB, and gain steps circuitry with relays ensuring that no un-linearly distortion is added to the sensitive microphone signal when amplified.The AX32 DA converter provides high-performance output level and gain control. With a level stepscircuitry using relays the outputs can directly drive a monitoring system, ensuring high dynamic range and no disturbing clicks when changing formats or powering down.Versatile digital interface structure.AX32 has a fixed configuration of digital interfaces for connecting via AES/EBU, S/PDIF, MADI, Pro Tools® and IP Ethernet audio compliant to Dante. One additional card slot is available for other interfaces which can be optionally installed. Currently this slot can hold an optical MADI or S/PDIF TosLink interface .Sync interfaces via word clock, AES11, Video, and all digital signal inputs. Sample rate can be set to internal or external, The sample rate can be set via all external devices.Rear panel layoutA total of 8 card slots are available in the chassis frame. 4 slots can be used for analogue cards each with 8 channels giving a total of 32 AD/DA input and outputs.The standard interface has the following capability:
8 AES3 I/O on two D25 connectors with 16 mono channels
MADI I/O on BNC connectors with 64 mono channels
Interface for Protools on SDR (min) connectors with 16 or 32 mono I/O channels
Interface for IP Ethernet audio on two redundant RJ45
connectors with 64 mono I/O channels powered by Dante
Flexible AD/DA interface configuration, with mic-pre option
8 to 32 channel AD/DA
8 channels on a card
AD Mic-pre option
DA gain control
Sample rates 44,1 kHz up-to 384 kHz/DSD
High precision internal clock and PLL
Versatile digital interface structure
8 AES3 I/O interfaces
MADI coax and optical I/O
Interface for Pro Tools (TM)
Ethernet IP audio interface for 64 I/O channels using Dante(TM)
Synch via word clock, AES11, Video, and all digital I/O
Adapt to incoming sample rate
Optional channel patching and multiplexer engine
Easy control of converter parameters
Settings control via front panel knobs and large LCD display
Operation via DADman control software for Windows and OSX
Ethernet control interface
Compliant with the Dante Ethernet controlle
Allgemeine Beschreibung
MOM ist der perfekte Begleiter, wenn Sie die Monitor-Controller-Funktionen des Avid MTRX, MTRX Studio, DAD AX32 oder NTP Penta 721s nutzen.
MOM ist eine Fernbedienung für das Pro|Mon Monitorprofil in der DADman Steuerungssoftware. Sie verfügt über 10 frei programmierbare Tasten, einen Drehregler und einen GPI-Eingang für einen externen Schalter. Sie können fast jede Funktion des Monitorprofils einer beliebigen Taste des MOM zuweisen, so dass Sie es leicht für Ihre speziellen Anforderungen konfigurieren können. Darüber hinaus bietet das MOM 4 Tastenebenen mit insgesamt 40 programmierbaren Tasten.
Mit einem Gewicht von 2 Pfund ist das MOM robust und bleibt an seinem Platz, ist aber gleichzeitig kompakt genug, um keinen wertvollen Platz auf dem Schreibtisch zu beanspruchen. Der Drehregler für die Lautstärkeregelung wurde sorgfältig für eine hervorragende Haptik entwickelt und verfügt über farbige LEDs, die die Lautstärkeeinstellung in 0,5 dB-Schritten anzeigen.
Während er in Kombination mit der DADman-Software perfekt funktioniert, zeigt sich seine wahre Stärke in Verbindung mit EUCON-Bedienoberflächen wie dem Avid Dock, S4, S6 oder sogar der kostenlosen Control-App, da der MOM-Betrieb mit diesen Geräten synchronisiert ist. Wählen Sie einfach z.B. eine Quelle auf dem Dock aus und die entsprechende Taste auf dem MOM leuchtet auf und umgekehrt, was Sie auf dem MOM tun, wird auch auf dem Dock reflektiert.
Sie können das MOM aber nicht nur in Kombination mit EUCON-Bedienoberflächen verwenden, sondern auch mehrere MOMs auf demselben System einsetzen. Dies ist besonders praktisch, wenn Sie mehrere Arbeitsplätze oder Abhörpositionen haben, z. B. einen Tontechniker- und einen Regieplatz, da Sie das MOM dort platzieren können, wo es benötigt wird.
Das MOM verfügt auch über einen GPI-Eingang, der für einen externen Schalter verwendet werden kann, z. B. einen Fußschalter oder einen separaten Schalter am Pult. Die Funktion des GPI-Eingangs kann genau wie die der Tasten programmiert werden.
Sie können das MOM entweder über PoE mit Strom versorgen, was die Installation sehr einfach macht, oder über ein mitgeliefertes Netzgerät.
Das MOM wird in Dänemark hergestellt und besticht durch sein schlankes und elegantes Design, das sich in jedem Studio sehen lassen kann.
Eigenschaften
MOM bietet Ihnen alles, was Sie von einem erstklassigen Hardware-Monitor-Controller erwarten:
- Großer Drehregler in Top-Qualität- Umschalten zwischen verschiedenen Quellen- Umschalten zwischen verschiedenen Monitor-Konfigurationen (von Mono bis Atmos)- Mute/Solo einzelner Monitorkanäle- Talkback- Dimmen- Trimmen- Referenzpegel
Highlights
- DSP/FPGA Card for AX32- Room Tuning with up to 16 Filters Per Channel- Bass Management with Support for Multiple Subs- 1024 IIR Filters- 128 channels @ 48 kHz- Sample Rates from 44,1 to 384 kHz- Adjustable Latency up to 800ms Per Channel- Speaker Match Between Various Immersive Audio Formats
Details
The SPQ – Speaker Processor Card is mounted in the 8-slot card section of the AX32 base unit. Normally one card is installed, but if more channels are needed more cards can be installed. The SPQ card does not have any I/O connectivity as it is a pure processing card. The SPQ card provides filters for channel-based speaker EQ and well as Bass Management.
The SPQ – Speaker Processor Card can be configured to various different filter characteristics and channel layouts via the DADman control software and is all integrated and easily managed by the Pro|Mon monitor control section in DADman. The SPQ Card supports all the system sample rates and will reconfigure automatically and fast when sample rates are changed, with equal filters and delay independent of the sample rate. Delay can be set individually per channel as well as generally for a whole set of speakers to also accommodate lip-sync applications.
The SPQ setting is stored in the Pro|Mon monitor profile in DADman, and speaker settings can be recalled separately from stored monitor profiles for fast change of parameters.
Measurement of the speaker curves and frequency responses have to be done using a separate measurement program, as this is not a part of the SPQ and Pro|Mon functionality.
The block diagram of the SPQ Speaker Processor card is shown below.
2.079,00 €*
Diese Website verwendet Cookies, um eine bestmögliche Erfahrung bieten zu können. Mehr Informationen ...
